Позиция на иллюстрации
Заводской номер детали
Название детали
1
72623
THROTTLE CONNECTOR
2
104265
HYDRAULIC HOSE
3
27441
HYDRAULIC HOSE
4
5930
MALE STUD COUPLING
5
2124509
DIRECTIONAL VALVE
6
2124511
SOLENOID COIL
7
5493
SCREW
8
43402
O-RING SEAL
9
10766
O-RING SEAL
10
2162184
PLUG
11
2162187
LOCKING MECHANISM
12
117269
CRIMP CONNECTOR
13
2115541
LATCH
14
2116500
BOLT
15
5854
SPLIT PIN
16
10744
SPRING HOOK
17
8755
TENSION SPRING
18
170482
RING NUT
19
4179
SCREW
20
5206
WASHER
