Каталог запасных частей к технике: WIRTGEN W200. SCANNER MILLING DRUM
2
2
10
10
11
11
12
12
13
13
14
14
15
15
16
17
17
18
18
19
19
19
19
20
20
21
22
22
25
25
26
26
28
29
30
31
32
32
32
32
34
34
35
35
35
35
36
37
37
38
38
39
39
40
40
41
41
43
43
44
45
46
48
54
54
55
55
56
56
56
57
57
58
58
59
59
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 72070 | BOLT | |
| 10 | 4822 | WASHER | |
| 11 | 9854 | SPLIT PIN | |
| 12 | 2139332 | SENSORING ARM | |
| 13 | 9065 | GREASING NIPPLE | |
| 14 | 11181 | CAP | |
| 15 | 2184817 | MOUNTING FIXTURE | |
| 16 | 2194699 | BOLT | |
| 17 | 2219386 | PROTECTOR SKID | |
| 18 | 4281 | SCREW | |
| 19 | 5195 | WASHER | |
| 20 | 5192 | HEXAGON NUT | |
| 21 | 2219389 | PIPE | |
| 22 | 2452319 | STOP | |
| 25 | 30243 | MALE STUD COUPLING | |
| 26 | 30243 | MALE STUD COUPLING | |
| 28 | 98876 | HYDRAULIC HOSE | |
| 29 | 169410 | HYDRAULIC HOSE | |
| 30 | 80674 | HYDRAULIC HOSE | |
| 31 | 2122185 | VALVE BLOCK | |
| 32 | 2138485 | SOLENOID COIL | |
| 34 | 2148632 | PRESSURE REDUCTION VALVE | |
| 35 | 30243 | MALE STUD COUPLING | |
| 36 | 9922 | SCREWED SEALING PLUG | |
| 37 | 31428 | ADJUSTABLE MALE STUD ELBOW | |
| 38 | 4643 | SCREWED JOINT | |
| 39 | 1126 | MALE STUD COUPLING | |
| 40 | 184292 | HYDRAULIC HOSE | |
| 41 | 3934 | MALE STUD COUPLING | |
| 43 | 2113307 | SET OF SEALS | |
| 44 | 2162184 | PLUG | |
| 45 | 2162187 | LOCKING MECHANISM | |
| 46 | 117269 | CRIMP CONNECTOR | |
| 48 | 175755 | HYDRAULIC HOSE | |
| 54 | 2103475 | HYDRAULIC CYLINDER W POSITION MEASURING | |
| 55 | 70443 | BOLT | |
| 56 | 10328 | CIRCLIP | |
| 57 | 2068135 | BASE CARTRIDGE | |
| 58 | 2563961 | FORK HEAD | |
| 59 | 2139608 | ADAPTER CABLE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
