Каталог запасных частей к технике: WIRTGEN W200. LEVELING BOOM, SHIFTING
2
2
3
3
4
4
5
6
7
8
9
9
10
10
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
18
18
18
19
20
21
22
23
24
25
26
27
28
28
29
30
31
32
33
34
35
36
37
38
39
39
42
42
43
44
45
46
46
47
48
49
49
50
51
52
52
53
53
54
54
55
56
56
57
58
59
61
61
62
62
62
63
63
63
63
64
64
64
64
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 2168587 | TELESCOPIC TUBE | |
| 3 | 2168570 | TELESCOPIC TUBE | |
| 4 | 2168502 | TELESCOPIC TUBE | |
| 5 | 2203678 | FRAME | |
| 6 | 2166312 | COMPRESSION SPRING | |
| 7 | 2168327 | BOLT | |
| 8 | 1350 | CLAMPING SLEEVE | |
| 9 | 98219 | ROD END BALL JOINT | |
| 10 | 10442 | CIRCLIP | |
| 11 | 34465 | BOLT | |
| 12 | 5158 | WASHER | |
| 13 | 7890 | SPRING PIN | |
| 14 | 2165699 | HYDRAULIC CYLINDER | |
| 15 | 5930 | MALE STUD COUPLING | |
| 16 | 80602 | BANJO COUPLING,ONE-PIECE BOLT | |
| 17 | 2887 | ADJ.MALE STUD TEE-STUD BARREL | |
| 18 | 2167186 | CLAMPING ELEMENT | |
| 19 | 2172162 | BURNT PART | |
| 20 | 2172164 | STRIP | |
| 21 | 199717 | SCREW | |
| 22 | 2224938 | HANDLE SCREW | |
| 23 | 2169083 | BURNT PART | |
| 24 | 7890 | SPRING PIN | |
| 25 | 2175386 | ENERGY CHAIN | |
| 26 | 6075 | SCREW | |
| 27 | 6684 | CAP NUT | |
| 28 | 5800 | WASHER | |
| 29 | 158946 | PIPE CLIP | |
| 30 | 5943 | SCREW | |
| 31 | 5800 | WASHER | |
| 32 | 15607 | HYDRAULIC HOSE | |
| 33 | 85357 | HYDRAULIC HOSE | |
| 34 | 2124509 | DIRECTIONAL VALVE | |
| 35 | 172173 | NON-RETURN VALVE | |
| 36 | 5491 | SCREW | |
| 37 | 17180 | END PLATE | |
| 38 | 5495 | SCREW | |
| 39 | 30243 | MALE STUD COUPLING | |
| 42 | 9922 | SCREWED SEALING PLUG | |
| 43 | 7164 | SCREWED SEALING PLUG | |
| 44 | 142727 | O-RING SEAL | |
| 45 | 176214 | MANIFOLD PLATE | |
| 46 | 199180 | HYDRAULIC HOSE | |
| 47 | 2175246 | HYDRAULIC HOSE | |
| 48 | 2175244 | HYDRAULIC HOSE | |
| 49 | 2886 | STRAIGHT COUPLING | |
| 50 | 1499 | MALE STUD COUPLING | |
| 51 | 1126 | MALE STUD COUPLING | |
| 52 | 199180 | HYDRAULIC HOSE | |
| 53 | 3934 | MALE STUD COUPLING | |
| 54 | 43402 | O-RING SEAL | |
| 55 | 10766 | O-RING SEAL | |
| 56 | 2124511 | SOLENOID COIL | |
| 57 | 2162184 | PLUG | |
| 58 | 2162187 | LOCKING MECHANISM | |
| 59 | 117269 | CRIMP CONNECTOR | |
| 61 | 2203689 | HOLDER | |
| 62 | 5612 | SCREW | |
| 63 | 5131 | WASHER | |
| 64 | 5134 | HEXAGON NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
