Каталог запасных частей к технике: WIRTGEN W200. HYDRAULIC AGGREGAT
1
2
3
4
5
6
7
8
9
9
9
10
11
12
13
14
15
16
17
18
19
20
21
25
25
26
26
27
28
28
29
29
29
30
30
30
31
32
33
33
34
34
35
36
37
37
38
38
39
39
40
40
41
42
43
44
45
46
47
48
48
48
49
50
51
52
53
54
55
56
57
58
59
60
60
61
62
63
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2301511 | HYDR.POWER UNIT | |
| 2 | 4179 | SCREW | |
| 3 | 51957 | WASHER | |
| 4 | 2178492 | COVER SHEET | |
| 5 | 2112628 | NUT | |
| 6 | 4219 | SCREW | |
| 7 | 5274 | WASHER | |
| 8 | 12184 | LOCKING SCREW | |
| 9 | 3622 | MALE STUD COUPLING | |
| 10 | 1688 | HYDRAULIC HOSE | |
| 11 | 20985 | HYDRAULIC HOSE | |
| 12 | 108264 | HYDRAULIC HOSE | |
| 13 | 2123502 | FUSE HOLDER | |
| 14 | 6073 | SCREW | |
| 15 | 5800 | WASHER | |
| 16 | 49470 | HYDRAULIC HOSE | |
| 17 | 2240780 | BANJO COUPLING,ONE-PIECE BOLT | |
| 18 | 124157 | MANUAL PUMP | |
| 19 | 121362 | PIPE | |
| 20 | 4218 | SCREW | |
| 21 | 5274 | WASHER | |
| 25 | 4941 | MALE STUD COUPLING | |
| 26 | 125059 | HYDRAULIC HOSE | |
| 27 | 195633 | ADJUSTABLE MALE STUD ELBOW | |
| 28 | 166345 | ADAPTER | |
| 29 | 2071407 | COUPLING PLUG | |
| 30 | 2071408 | COUPLING SLEEVE | |
| 31 | 2071410 | PROTECTING PLUG | |
| 32 | 2071409 | DUST CAP | |
| 33 | 5930 | MALE STUD COUPLING | |
| 34 | 179831 | HYDRAULIC HOSE | |
| 35 | 2132547 | THROTTLE CONNECTOR | |
| 36 | 5930 | MALE STUD COUPLING | |
| 37 | 2888 | ADJUSTABLE MALE STUD ELBOW | |
| 38 | 15607 | HYDRAULIC HOSE | |
| 39 | 1126 | MALE STUD COUPLING | |
| 40 | 3929 | ADJ.MALE STUD TEE-STUD BARREL | |
| 41 | 19567 | ADJUSTABLE EQUAL TEE | |
| 42 | 31446 | CAP NUT | |
| 43 | 5971 | DUMMY PLUG | |
| 44 | 20979 | HYDRAULIC HOSE | |
| 45 | 2229423 | HOLDER | |
| 46 | 4179 | SCREW | |
| 47 | 51957 | WASHER | |
| 48 | 1126 | MALE STUD COUPLING | |
| 49 | 31446 | CAP NUT | |
| 50 | 5971 | DUMMY PLUG | |
| 51 | 4643 | SCREWED JOINT | |
| 52 | 1126 | MALE STUD COUPLING | |
| 53 | 2105128 | STUD STANDPIPE ADAPTOR | |
| 54 | 2886 | STRAIGHT COUPLING | |
| 55 | 5930 | MALE STUD COUPLING | |
| 56 | 31428 | ADJUSTABLE MALE STUD ELBOW | |
| 57 | 2161938 | VALVE BLOCK | |
| 58 | 2099891 | BASE CARTRIDGE | |
| 59 | 2252157 | DIRECTIONAL VALVE | |
| 60 | 2118668 | SOLENOID COIL | |
| 61 | 54126 | HYDRAULIC HOSE | |
| 62 | 1126 | MALE STUD COUPLING | |
| 63 | 2375805 | ELECTROMOTOR |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
