Каталог запасных частей к технике: WIRTGEN W200. HYDRAULIC ACCESSORIES

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
11
12
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
41
42
49
50
51
52
57
Позиция на иллюстрации Заводской номер детали Название детали
1 85249 SERVICE SET HYDRAULICS
2 4569 MANOMETER CONNECTOR
3 4572 MANOMETER CONNECTOR
4 148777 MEASURING CONNECTOR
5 4575 MEASURING CONNECTOR
6 4570 MEASURING CONNECTOR
7 4571 SCREW COUPLING
8 4574 SCREW COUPLING
9 4643 SCREWED JOINT
10 4645 SCREW COUPLING
11 148778 MEASURING CONNECTOR
12 51005 STRAIGHT COUPLING
14 2995 STRAIGHT REDUCING COUPLING
15 4942 STRAIGHT REDUCING COUPLING
16 5047 REDUCING COUPLING
17 2887 ADJ.MALE STUD TEE-STUD BARREL
18 3929 ADJ.MALE STUD TEE-STUD BARREL
19 2886 STRAIGHT COUPLING
20 5000 CAP NUT
21 5981 CUTTING RING
22 3926 STRAIGHT COUPLING
23 31446 CAP NUT
24 3800 CUTTING RING
25 3924 STRAIGHT COUPLING
26 3798 UNION NUT
27 3927 MALE STUD COUPLING
28 1500 MALE STUD COUPLING
29 3551 MALE STUD COUPLING
30 4998 MALE STUD COUPLING
31 4999 PARALLE FEMALE STUD COUPLING
32 13836 MALE STUD COUPLING
33 3622 MALE STUD COUPLING
34 2875 MALE STUD COUPLING
35 4959 PARALLE FEMALE STUD COUPLING
36 11179 SEALING RING
37 3995 STRAIGHT COUPLING
38 3335 STRAIGHT COUPLING
39 2943 STRAIGHT COUPLING
40 3041 STRAIGHT COUPLING
41 3315 STRAIGHT COUPLING
42 5048 DUMMY PLUG
43 5971 DUMMY PLUG
44 4023 BLIND PLUG
45 3360 BLIND PLUG
46 3334 BLIND PLUG
47 3316 BLIND PLUG
48 3318 DUMMY PLUG
49 7977 BLIND PLUG
50 4148 SAE FLANGE-SHOULDER
51 51004 STRAIGHT COUPLING
52 3994 UNION NUT
53 3369 UNION NUT
54 2997 CAP NUT
55 3361 UNION NUT
56 2996 UNION NUT
57 2936 UNION NUT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
