Каталог запасных частей к технике: WIRTGEN W200. ENGINE ANCILLARY PARTS
1
2
4
6
6
7
7
8
8
9
9
9
9
10
10
10
10
10
10
11
11
11
11
11
11
12
12
13
14
15
16
16
17
17
18
18
20
21
22
22
23
23
24
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
52
53
54
55
55
56
57
58
59
60
61
62
62
63
64
64
65
66
67
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2296546 | DIESEL ENGINE | |
| 2 | 2131700 | VALVE | |
| 4 | 2111169 | ENGINE OIL FILTER | |
| 6 | 2137367 | ENGINE MOUNTING | |
| 7 | 7848 | SCREW | |
| 8 | 5131 | WASHER | |
| 9 | 2091828 | RUBBER BUFFER | |
| 10 | 4218 | SCREW | |
| 11 | 5274 | WASHER | |
| 12 | 2217047 | RUBBER/METAL CONE. | |
| 13 | 2121911 | ENGINE BRACKET | |
| 14 | 2121953 | HOLDER | |
| 15 | 2121937 | HOLDER | |
| 16 | 4313 | SCREW | |
| 17 | 4261 | SCREW | |
| 18 | 5195 | WASHER | |
| 20 | 2098577 | ENGINE BRACKET | |
| 21 | 2098576 | ENGINE BRACKET | |
| 22 | 4359 | SCREW | |
| 23 | 5158 | WASHER | |
| 24 | 2141210 | TREAD PLATE | |
| 28 | 2122220 | HEAT PROTECTION SHEET | |
| 29 | 2218121 | KIT HEAT PROTECTOR | |
| 30 | 2110864 | NUT | |
| 31 | 4218 | SCREW | |
| 32 | 5274 | WASHER | |
| 33 | 4220 | SCREW | |
| 34 | 5269 | HEXAGON NUT | |
| 35 | 4262 | SCREW | |
| 36 | 5195 | WASHER | |
| 37 | 51958 | WASHER | |
| 38 | 4219 | SCREW | |
| 39 | 5275 | WASHER | |
| 40 | 2171393 | POWER BELT | |
| 41 | 2184266 | POWER BELT | |
| 52 | 2188081 | PROTECTIVE COVER | |
| 53 | 12413 | SILENTBLOC | |
| 54 | 4217 | SCREW | |
| 55 | 51958 | WASHER | |
| 56 | 5269 | HEXAGON NUT | |
| 57 | 4219 | SCREW | |
| 58 | 5274 | WASHER | |
| 59 | 2112628 | NUT | |
| 60 | 2218696 | SUPPORT | |
| 61 | 159621 | SCREW | |
| 62 | 5269 | HEXAGON NUT | |
| 63 | 5274 | WASHER | |
| 64 | 51958 | WASHER | |
| 65 | 4221 | SCREW | |
| 66 | 4296 | SCREW | |
| 67 | 5134 | HEXAGON NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
