Каталог запасных частей к технике: WIRTGEN W200. ELECTRICAL CABINET ANC.PARTS
1
2
3
4
5
6
7
8
9
10
11
13
13
14
14
15
15
15
15
16
16
17
17
18
18
19
19
19
19
20
20
21
21
22
22
22
22
23
23
23
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
41
42
43
44
45
46
52
53
54
55
56
57
58
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2110534 | ELECTRICAL CABINET | |
| 2 | 2142368 | INSULATION PLATE | |
| 3 | 2113366 | CONNECTION ARMATURE | |
| 4 | 5498 | SCREW | |
| 5 | 5801 | WASHER | |
| 6 | 2122224 | ANGLE BRACKET | |
| 7 | 4217 | SCREW | |
| 8 | 5274 | WASHER | |
| 9 | 2063065 | MAGNET | |
| 10 | 5800 | WASHER | |
| 11 | 46115 | HEXAGON NUT | |
| 13 | 2172573 | ANGLE BRACKET | |
| 14 | 5941 | SCREW | |
| 15 | 5800 | WASHER | |
| 16 | 46115 | HEXAGON NUT | |
| 17 | 5274 | WASHER | |
| 18 | 4218 | SCREW | |
| 19 | 2122815 | SILENT BLOCK | |
| 20 | 5800 | WASHER | |
| 21 | 5940 | SCREW | |
| 22 | 5800 | WASHER | |
| 23 | 4179 | SCREW | |
| 24 | 2136011 | CONSOLE | |
| 25 | 5206 | WASHER | |
| 26 | 12247 | HEXAGON NUT | |
| 27 | 2134512 | HOOK | |
| 28 | 184036 | SCREW | |
| 29 | 5800 | WASHER | |
| 30 | 6441 | SCREW | |
| 31 | 171897 | HINGE | |
| 32 | 2073951 | SCREW | |
| 33 | 2135998 | FRAME | |
| 34 | 2128294 | LID | |
| 35 | 2073951 | SCREW | |
| 36 | 2308296 | CONTROL BOARD | |
| 37 | 2050201 | PLUG | |
| 38 | 2050229 | DUST CAP | |
| 39 | 160147 | CHAIN | |
| 40 | 182657 | SCREW | |
| 41 | 28705 | WASHER | |
| 42 | 182658 | HEXAGONAL NUT | |
| 43 | 34556 | RUBBER BUFFER | |
| 44 | 23080 | SCREW | |
| 45 | 31632 | WASHER | |
| 46 | 141948 | HEXAGONAL NUT | |
| 52 | 2261569 | CAN NODE | |
| 53 | 2245192 | STICKER | |
| 54 | 2245190 | STICKER | |
| 55 | 2245191 | STICKER | |
| 56 | 64000 | SPLICING TAPE | |
| 57 | 138270 | SCREW | |
| 58 | 31632 | WASHER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
