Каталог запасных частей к технике: WIRTGEN W200. DISPLACE CABIN
1
2
2
2
3
3
3
4
4
4
5
5
6
6
7
8
8
8
9
9
9
10
10
10
11
12
13
14
15
16
18
19
20
21
22
23
24
24
25
25
26
27
28
29
30
30
30
31
31
31
32
33
34
35
36
37
38
39
40
40
41
42
43
44
45
46
47
48
48
49
49
49
50
50
51
52
55
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2129399 | SHAFT | |
| 2 | 2129401 | RAIL | |
| 3 | 4264 | SCREW | |
| 4 | 5195 | WASHER | |
| 5 | 4299 | SCREW | |
| 6 | 2179033 | WASHER | |
| 7 | 2101291 | LID | |
| 8 | 4217 | SCREW | |
| 9 | 5274 | WASHER | |
| 10 | 2110864 | NUT | |
| 11 | 2134619 | ENERGY CHAIN | |
| 12 | 6075 | SCREW | |
| 13 | 2119665 | NUT | |
| 14 | 2161707 | ADAPTER | |
| 15 | 2073951 | SCREW | |
| 16 | 2101226 | COVER SHEET | |
| 18 | 154099 | STRIP | |
| 19 | 2095231 | TOOTHED BELT | |
| 20 | 2097750 | TOOTHED LOCK WASHER | |
| 21 | 2095344 | TENSIONING ASSEMBLY | |
| 22 | 43643 | HYDRAULIC MOTOR | |
| 23 | 39892 | FEATHER KEY | |
| 24 | 2093530 | PLATE | |
| 25 | 2104776 | TENSIONER PLATE | |
| 26 | 4212 | SCREW | |
| 27 | 5274 | WASHER | |
| 28 | 2131144 | MATERIAL DEPRESSOR | |
| 29 | 2098875 | LOAD-BEARING FRAME | |
| 30 | 4218 | SCREW | |
| 31 | 5274 | WASHER | |
| 32 | 10334 | CIRCLIP | |
| 33 | 10451 | CIRCLIP | |
| 34 | 11340 | GROOVED BALL BEARING | |
| 35 | 2098900 | TOOTHED WHEEL | |
| 36 | 2137805 | POTENTIOMETER | |
| 37 | 2098779 | HOLDER | |
| 38 | 2097748 | TOOTHED LOCK WASHER | |
| 39 | 2093676 | SLEEVE | |
| 40 | 33138 | GROOVED BALL BEARING | |
| 41 | 4822 | WASHER | |
| 42 | 2097972 | SPLINED AXLE | |
| 43 | 5853 | SPLIT PIN | |
| 44 | 2098014 | HOUSING | |
| 45 | 4220 | SCREW | |
| 46 | 51958 | WASHER | |
| 47 | 4319 | SCREW | |
| 48 | 5131 | WASHER | |
| 49 | 5134 | HEXAGON NUT | |
| 50 | 36126 | WASHER | |
| 51 | 4467 | SCREW | |
| 52 | 39929 | SEALING KIT CPL. | |
| 55 | 2304279 | COVER SHEET |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
