Каталог запасных частей к технике: WIRTGEN W200. CANOPY REAR WINDOW
1
2
3
3
4
5
5
6
6
7
7
8
9
9
9
10
10
10
10
10
10
11
11
11
12
12
13
13
14
14
15
15
18
18
19
19
20
20
21
21
22
23
24
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
33
34
35
36
37
38
39
40
41
42
43
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2198178 | WINDOW FRAME | |
| 2 | 2147607 | BOLT | |
| 3 | 5274 | WASHER | |
| 4 | 5846 | SPLIT PIN | |
| 5 | 2128639 | GAS SPRING | |
| 6 | 64591 | BOLT | |
| 7 | 9843 | SPLIT PIN | |
| 8 | 2124934 | LOCKING BAR | |
| 9 | 4193 | SCREW | |
| 10 | 5206 | WASHER | |
| 11 | 12247 | HEXAGON NUT | |
| 12 | 44801 | FASTENING | |
| 13 | 4178 | SCREW | |
| 14 | 5206 | WASHER | |
| 15 | 2125169 | RUBBER BUFFER | |
| 18 | 57480 | PLASTIC HANDLE | |
| 19 | 5942 | SCREW | |
| 20 | 5800 | WASHER | |
| 21 | 46115 | HEXAGON NUT | |
| 22 | 170097 | RUNNER | |
| 23 | 68267 | WASHER | |
| 24 | 5942 | SCREW | |
| 25 | 2136905 | WINDOW FRAME | |
| 26 | 170396 | SLIDE RAIL | |
| 27 | 2171416 | SCREW | |
| 28 | 5799 | WASHER | |
| 29 | 46115 | HEXAGON NUT | |
| 30 | 2124932 | STRIP | |
| 31 | 5800 | WASHER | |
| 32 | 2171416 | SCREW | |
| 33 | 2125136 | ACRYLIC GLASS SCREEN | |
| 34 | 192356 | INSERT | |
| 35 | 141906 | SEALING PROFILE | |
| 36 | 2136748 | STRIP | |
| 37 | 2136745 | STRIP | |
| 38 | 6438 | SCREW | |
| 39 | 5800 | WASHER | |
| 40 | 6684 | CAP NUT | |
| 41 | 2078592 | LOCATING PIN | |
| 42 | 2172675 | DISTANCE PIECE | |
| 43 | 21281 | SEALING RUBBER |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
