Позиция на иллюстрации
Заводской номер детали
Название детали
1
2103947
BACKPLATE
2
2101230
COVER SHEET
3
4217
SCREW
4
5274
WASHER
5
2110864
NUT
6
2161793
LOCKING PLUG
7
5616
SCREW
8
51958
WASHER
9
4218
SCREW
10
2133668
BOTTOM PLATE, RIGHT SIDE
11
2133656
BOTTOM PLATE, CENTRE
12
2133612
BOTTOM PLATE, LEFT SIDE
13
5616
SCREW
14
5274
WASHER
15
2110864
NUT
16
2167292
LOCKING MECHANISM
17
17815
SCREW
18
2163017
RAIL
19
4218
SCREW
20
39994
WASHER
21
170146
SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
