Каталог запасных частей к технике: WIRTGEN W200. CABIN HANDRAIL
1
2
3
3
4
5
6
7
8
9
10
11
12
12
12
12
12
13
13
13
13
13
14
14
14
14
14
15
16
16
16
16
17
18
19
20
21
22
23
24
24
25
25
26
27
28
29
29
30
31
32
33
34
35
36
37
38
39
40
40
41
41
42
43
44
45
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2154744 | HANDRAIL | |
| 2 | 5616 | SCREW | |
| 3 | 51958 | WASHER | |
| 4 | 5269 | HEXAGON NUT | |
| 5 | 2161605 | STRAP | |
| 6 | 5941 | SCREW | |
| 7 | 5800 | WASHER | |
| 8 | 2161597 | COVER | |
| 9 | 118459 | POSITION SWITCH | |
| 10 | 2160784 | OPERATING LEVER | |
| 11 | 33139 | GROOVED BALL BEARING | |
| 12 | 2160804 | WASHER | |
| 13 | 5195 | WASHER | |
| 14 | 4261 | SCREW | |
| 15 | 2154215 | BRACE | |
| 16 | 75632 | GROOVED BALL BEARING | |
| 17 | 4235 | SCREW | |
| 18 | 5274 | WASHER | |
| 19 | 2154292 | BEARING BLOCK | |
| 20 | 151173 | SCREW | |
| 21 | 51958 | WASHER | |
| 22 | 5269 | HEXAGON NUT | |
| 23 | 2165150 | GAS SPRING | |
| 24 | 64591 | BOLT | |
| 25 | 9843 | SPLIT PIN | |
| 26 | 2154077 | HANDRAIL, LEFT | |
| 27 | 183110 | LAMELLAR PLUG | |
| 28 | 2154298 | BRACE | |
| 29 | 14354 | BUSHING | |
| 30 | 2125171 | RUBBER BUFFER | |
| 31 | 5274 | WASHER | |
| 32 | 5267 | HEXAGONAL NUT | |
| 33 | 2179751 | COVER | |
| 34 | 5940 | SCREW | |
| 35 | 5800 | WASHER | |
| 36 | 2119665 | NUT | |
| 37 | 2202208 | RUBBER PROTECTIVE | |
| 38 | 2202232 | STRIP | |
| 39 | 2202231 | STRIP | |
| 40 | 7203 | SCREW | |
| 41 | 2198743 | BUSHING | |
| 42 | 2160726 | ANGLE | |
| 43 | 4223 | SCREW | |
| 44 | 5274 | WASHER | |
| 45 | 51958 | WASHER | |
| 46 | 5269 | HEXAGON NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
