Каталог запасных частей к технике: WIRTGEN W1900. SIDE PLATE FB2000
1
2
3
3
4
4
5
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
14
15
16
17
18
18
18
18
19
19
19
19
20
20
20
20
21
21
21
21
22
22
23
23
24
24
24
24
25
25
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
39
39
40
41
42
43
44
45
46
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 145351 | SIDE PLATE | |
| 2 | 143093 | EDGE PROTECTION | |
| 3 | 141749 | WEAR PLATE | |
| 4 | 4314 | SCREW | |
| 5 | 5151 | HEXAGON NUT | |
| 6 | 113001 | PROTECTOR SKID 40X180 | |
| 6 | 113001 | PROTECTOR SKID 40X180 | |
| 7 | 148982 | SCREW | |
| 8 | 39994 | WASHER | |
| 9 | 5192 | HEXAGON NUT | |
| 10 | 57718 | SPACER PLATE | |
| 11 | 57719 | COVER PLATE | |
| 12 | 4618 | SCREW | |
| 13 | 141888 | SLIDE | |
| 14 | 147408 | SCREWED SEALING PLUG | |
| 15 | 58436 | REINFORCEMENT | |
| 16 | 4219 | SCREW | |
| 17 | 5275 | WASHER | |
| 18 | 69522 | ROPE EYE | |
| 19 | 4091 | WASHER | |
| 20 | 4219 | SCREW | |
| 21 | 8026 | WIRE CLIP | |
| 22 | 34465 | BOLT | |
| 23 | 104971 | BOLT | |
| 24 | 9851 | SPLIT PIN | |
| 25 | 5158 | WASHER | |
| 26 | 145469 | BOWDEN CABLE | |
| 27 | 145470 | BOWDEN CABLE | |
| 28 | 145471 | BOWDEN CABLE | |
| 29 | 142244 | BOWDEN CABLE | |
| 30 | 58605 | PIPE CLIP | |
| 31 | 5274 | WASHER | |
| 32 | 6219 | CAP NUT | |
| 33 | 146384 | COVER | |
| 34 | 5941 | SCREW | |
| 35 | 5803 | WASHER | |
| 36 | 5810 | HEXAGON NUT | |
| 37 | 144626 | COVER | |
| 38 | 4218 | SCREW | |
| 39 | 5274 | WASHER | |
| 40 | 35436 | FLASHLIGHT | |
| 41 | 19168 | SCREW | |
| 42 | 20431 | HEXAGON NUT | |
| 43 | 31632 | WASHER | |
| 44 | 10183 | BULB | |
| 45 | 155630 | PROTECTOR SKID 50X625 | |
| 46 | 4316 | SCREW |
