Каталог запасных частей к технике: WIRTGEN W1900. LIGHTS/WARNINGS
1
2
3
4
5
5
6
7
8
9
10
10
10
10
10
10
11
11
11
12
12
12
13
14
14
14
15
16
17
17
18
18
19
20
20
21
21
22
23
23
23
24
25
25
26
26
26
26
26
26
27
28
29
30
30
31
32
32
33
34
35
35
36
37
38
40
41
42
43
44
45
45
46
47
48
48
49
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 10906 | WORKING LIGHT | |
| 2 | 10251 | SPIRAL CABLE | |
| 3 | 117675 | MAGNETIC BRACKET | |
| 4 | 12806 | PLUG | |
| 5 | 9778 | BULB FOR WORK LIGHT | |
| 6 | 8015 | HORN | |
| 7 | 52599 | FREE WHEEL DIODE CPL. | |
| 8 | 117676 | WORK LIGHT WITH MAGNETIC BRACK | |
| 9 | 68407 | PATROL LIGHT YELLOW | |
| 10 | 57775 | WORK LIGHT W. QUICK FASTENING | |
| 11 | 63882 | LAMPHOLDER WITH SOCKET | |
| 12 | 65068 | SERRATED LOCK WASHER | |
| 13 | 9560 | PLUG SOCKET | |
| 14 | 28825 | PROTECTING CAP | |
| 15 | 39231 | WARNING PLATE | |
| 16 | 39232 | WARNING PLATE | |
| 17 | 8647 | PADLOCK | |
| 18 | 65172 | MOUNTING DEVICE | |
| 19 | 56498 | WARNING PLATE | |
| 20 | 8477 | SCREW | |
| 21 | 5800 | WASHER | |
| 22 | 52070 | WARNING PLATE | |
| 23 | 7982 | PLUG SOCKET | |
| 24 | 5210 | HEXAGON NUT | |
| 25 | 5206 | WASHER | |
| 26 | 4179 | SCREW | |
| 26 | 4179 | SCREW | |
| 27 | 16224 | BULB FOR PATROL LIGHT | |
| 28 | 7983 | PLUG SOCKET | |
| 29 | 19836 | REVERSING ALARM | |
| 30 | 4242 | SCREW | |
| 30 | 4244 | SCREW | |
| 31 | 5269 | HEXAGON NUT | |
| 32 | 51958 | WASHER | |
| 33 | 161887 | SUPPORT | |
| 34 | 4370 | SCREW | |
| 35 | 5208 | WASHER | |
| 36 | 5211 | WASHER | |
| 37 | 133137 | SILENTBLOC | |
| 38 | 131621 | SCREW | |
| 40 | 8015 | HORN | |
| 41 | 52599 | FREE WHEEL DIODE CPL. | |
| 42 | 163211 | SUPPORT | |
| 43 | 54206 | CABLE BUSH | |
| 44 | 4179 | SCREW | |
| 45 | 5206 | WASHER | |
| 46 | 12247 | HEXAGON NUT | |
| 47 | 4261 | SCREW | |
| 48 | 5195 | WASHER | |
| 49 | 5192 | HEXAGON NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
