Каталог запасных частей к технике: WIRTGEN W1900. HEIGHT ADJUSTMENT REAR

Тип техники

Марка

Модель

Схема

1

1

2

2

3

3

4

4

5

5

6

6

7

7

8

8

9

9

10

10

11

11

12

12

12

12

13

14

15

16

16

17

18

18

19

20

21

21

22

23

23

24

24

25

26

27

28

29

30

30

31

31

32

32

33

33

34

35

36

37

38

38

39

40

41

42

43

44

45

46

46

47

48

48

49

Позиция на иллюстрации	Заводской номер детали		Название детали
1	153065		UNDERCARRIAGE BRACKET
2	53194		BOLT
3	4219		SCREW
4	63063		HYDRAULIC CYLINDER
5	64799		SET OF SEALS
6	4302		SCREW
7	90726		SUPPORT
8	4293		SCREW
9	5131		WASHER
10	90725		ROD
11	5151		HEXAGON NUT
12	1126		MALE STUD COUPLING
13	1705		HYDRAULIC HOSE
14	19567		ADJUSTABLE EQUAL TEE
15	16535		HYDRAULIC HOSE
16	3929		ADJ.MALE STUD TEE-STUD BARREL
17	4453		ORIFICE CHECK VALVE
18	51005		STRAIGHT COUPLING
19	64388		THROTTLE CONNECTOR
20	115759		THROTTLE CONNECTOR
21	9922		SCREWED SEALING PLUG
22	4646		MEASURING CONNECTOR
23	3997		HYDRAULIC HOSE
23	1676		HYDRAULIC HOSE
24	1499		MALE STUD COUPLING
25	4560		NONRETURN VALVE
26	53644		NONRETURN VALVE
27	14745		SET OF SEALS
28	114161		SET OF SEALS
29	114131		DIRECTIONAL VALVE
30	114160		SOLENOID
31	21041		SEAL
32	131097		FEMALE PLUG
33	130268		RELIEF VALVE
34	16920		PRESSURE REDUCTION VALVE
35	14747		SET OF SEALS
36	55213		SUPPORT
37	4257		SCREW
38	5195		WASHER
39	5193		HEXAGON NUT
40	11181		CAP
41	1105		GREASING NIPPLE
42	42930		BULKHEAD COUPLING
43	2888		ADJUSTABLE MALE STUD ELBOW
44	1641		HYDRAULIC HOSE
45	4941		MALE STUD COUPLING
46	36908		PLUG
47	87769		FEMALE PLUG
48	55662		PROXIMITY SWITCH
48	187786		PROXIMITY SWITCH
49	21776		CABLE JOINT

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
