Каталог запасных частей к технике: WIRTGEN W1900. FUEL SUPPLY
1
2
3
4
5
5
6
7
8
9
10
11
12
13
13
14
15
16
17
18
18
18
19
20
20
20
21
22
23
24
25
26
27
27
28
29
30
30
31
32
33
34
35
36
37
38
39
40
41
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 142329 | TANK CAP | |
| 2 | 6219 | CAP NUT | |
| 3 | 66346 | TANK LEVEL SENSOR | |
| 4 | 19171 | COPPER RING | |
| 5 | 120371 | VALVE | |
| 5 | 120382 | VALVE | |
| 6 | 124201 | CONNECTOR | |
| 7 | 124203 | FUEL HOSE | |
| 8 | 143027 | MALE STUD COUPLING | |
| 9 | 7166 | BALL-CLOSURE COCK | |
| 10 | 141483 | STUD STANDPIPE ADAPTOR | |
| 11 | 4970 | ADJUSTABLE MALE STUD ELBOW | |
| 12 | 20930 | MALE STUD COUPLING | |
| 13 | 10838 | O-RING SEAL | |
| 14 | 122647 | FUEL FILTER | |
| 15 | 122648 | FUEL PREFILTER/WATER SEPARATOR | |
| 16 | 151552 | SET OF SEALS | |
| 17 | 5205 | SCREW | |
| 18 | 5206 | WASHER | |
| 19 | 147287 | INTERMEDIATE PIECE | |
| 20 | 5211 | WASHER | |
| 21 | 12247 | HEXAGON NUT | |
| 22 | 3287 | HOSE CLAMP | |
| 23 | 10222 | FUEL HOSE | |
| 24 | 3927 | MALE STUD COUPLING | |
| 25 | 31428 | ADJUSTABLE MALE STUD ELBOW | |
| 26 | 51005 | STRAIGHT COUPLING | |
| 27 | 3551 | MALE STUD COUPLING | |
| 28 | 147164 | PLATE | |
| 29 | 5204 | SCREW | |
| 30 | 5210 | HEXAGON NUT | |
| 31 | 4181 | SCREW | |
| 32 | 145128 | FUEL HOSE | |
| 33 | 145112 | FUEL HOSE | |
| 34 | 57947 | SEALANT | |
| 35 | 3353 | TANK CAP | |
| 36 | 100505 | ANTISLIP FLOOR COVERING | |
| 37 | 51183 | ADHESIVE | |
| 38 | 145940 | FUEL FILTER | |
| 39 | 165550 | STICKERS | |
| 40 | 3367 | CAP NUT | |
| 41 | 3342 | CUTTING RING | |
| 43 | 2091064 | MANUAL PUMP |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
