Каталог запасных частей к технике: WIRTGEN W1900. DRUM BEARING FCS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
25
26
27
28
29
30
31
32
33
34
34
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 148639 | V-BELT PULLEY | |
| 2 | 4469 | SCREW | |
| 3 | 39994 | WASHER | |
| 4 | 147402 | ADAPTER | |
| 5 | 8338 | CLAMPING SLEEVE | |
| 6 | 4370 | SCREW | |
| 7 | 16765 | SCREW | |
| 8 | 127868 | SUPPORT | |
| 9 | 127867 | SUPPORT | |
| 10 | 3904 | BUSHING | |
| 11 | 80355 | BOLT | |
| 12 | 5854 | SPLIT PIN | |
| 13 | 4681 | SCREW | |
| 14 | 29709 | T-SLOT NUT | |
| 15 | 5925 | SCREW | |
| 16 | 10801 | SCREW | |
| 17 | 133465 | GEARBOX | |
| 18 | 127012 | FLANGE | |
| 19 | 114251 | SCREW | |
| 20 | 20218 | SCREW | |
| 21 | 127172 | THREADED BOLT | |
| 22 | 62261 | HEXAGON NUT | |
| 23 | 127561 | PROTECTIVE TUBE | |
| 24 | 127512 | PROTECTIVE TUBE | |
| 25 | 127523 | CLOSING PLATE | |
| 25 | 127523 | CLOSING PLATE | |
| 26 | 21899 | SCREW | |
| 27 | 103691 | HEADLESS SCREW M16X6 COATING | |
| 28 | 1105 | GREASING NIPPLE | |
| 29 | 11181 | CAP | |
| 30 | 49027 | SCREWED SEALING PLUG | |
| 31 | 149254 | BACKPLATE | |
| 32 | 51958 | WASHER | |
| 33 | 4218 | SCREW | |
| 34 | 150374 | SEALING PLATE | |
| 35 | 5206 | WASHER | |
| 36 | 4368 | SCREW | |
| 37 | 70821 | CRANK | |
| 38 | 170379 | CLOSING PLATE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
