Каталог запасных частей к технике: WIRTGEN W1900. COMBINED COOLER
1
1
1
1
2
3
3
4
4
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 177767 | COMBINED COOLER | |
| 1 | 141559 | COMBINED COOLER | |
| 2 | 192844 | OIL COOLER | |
| 3 | 50431 | COOLER LID | |
| 3 | 192808 | COOLER LID | |
| 4 | 4264 | SCREW | |
| 5 | 111802 | WASHER | |
| 6 | 5195 | WASHER | |
| 7 | 5193 | HEXAGON NUT | |
| 8 | 89818 | HYDRAULIC MOTOR | |
| 9 | 24159 | SEALING KIT CPL. | |
| 10 | 122473 | LEVEL MONITORING | |
| 11 | 20136 | PLUG SOCKET | |
| 12 | 47566 | SILENTBLOC | |
| 13 | 4263 | SCREW | |
| 14 | 77840 | WASHER | |
| 15 | 38451 | SILENT BLOCK | |
| 16 | 4218 | SCREW | |
| 17 | 5274 | WASHER | |
| 18 | 19171 | COPPER RING | |
| 19 | 120371 | VALVE | |
| 20 | 124201 | CONNECTOR | |
| 21 | 144134 | SEALING PLATE | |
| 22 | 5268 | HEXAGON NUT | |
| 23 | 59137 | BRUSH STRIP | |
| 24 | 5940 | SCREW | |
| 25 | 16250 | PIPE CLIP | |
| 26 | 5800 | WASHER | |
| 27 | 5810 | HEXAGON NUT | |
| 28 | 145905 | SEALING PLATE | |
| 29 | 145964 | SEALING PLATE | |
| 30 | 4220 | SCREW | |
| 31 | 5274 | WASHER | |
| 32 | 5269 | HEXAGON NUT | |
| 33 | 36350 | SEALING PROFILE | |
| 34 | 144355 | SEALING PLATE | |
| 35 | 4217 | SCREW | |
| 36 | 159264 | FAN BLADE | |
| 37 | 192841 | AIR COOLER | |
| 38 | 192839 | COMPENSATOR TANK | |
| 39 | 192842 | WATER COOLER ELEMENT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
