Каталог запасных частей к технике: WIRTGEN W1900. CANOPY

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
6
7
7
7
7
7
7
7
7
7
7
8
8
8
8
8
9
9
10
11
11
11
11
11
11
11
12
12
13
14
15
16
17
17
18
19
20
20
20
21
21
22
23
24
25
25
26
27
28
28
29
29
30
30
31
32
33
34
35
35
36
37
37
38
38
39
39
40
41
42
43
43
44
45
45
45
46
47
48
48
49
49
50
51
52
53
53
54
55
56
57
57
58
59
60
61
61
61
61
61
62
63
63
64
64
65
66
67
68
69
70
71
72
73
74
75
76
76
77
78
79
79
79
80
80
81
82
85
86
87
88
89
90
91
91
Позиция на иллюстрации Заводской номер детали Название детали
1 170392 CENTRAL SECTION
2 170393 SIDE PART
3 170394 SIDE PART
4 194253 WINDOW FRAME
5 194105 BOW
6 4237 SCREW
7 5274 WASHER
8 5269 HEXAGON NUT
9 172607 BURNT PART
10 131753 SCREW
11 5206 WASHER
12 6683 CAP NUT
13 174009 HOOK
14 109218 LATCH CLOSING
15 194121 WINDOW FRAME
16 37220 HINGE
17 4178 SCREW
18 198717 ACRYLIC GLASS SCREEN
19 194108 MOUNTING
20 4180 SCREW
21 198848 REST
22 4219 SCREW
23 51958 WASHER
24 192355 ACRYLIC GLASS SCREEN
25 192356 INSERT
26 141906 SEALING PROFILE
27 17439 SILENTBLOC
28 147713 SEALING RUBBER
29 147732 RAIL
30 12247 HEXAGON NUT
31 170388 BURNT PART
32 170389 BURNT PART
33 170391 WASHER
34 170386 BURNT PART
35 170387 BENT PART
36 170385 BENT PART
37 173551 BENT PART
38 173959 RETAINER STRIP
39 170096 GUIDE RAIL
40 4368 SCREW
41 131621 SCREW
42 133137 SILENTBLOC
43 170097 RUNNER
44 6074 SCREW
45 5800 WASHER
46 170098 ROLLER
47 5497 SCREW
48 170091 LATCH CLOSING
49 170093 FASTENER
50 5940 SCREW
51 5799 WASHER
52 6073 SCREW
53 12247 HEXAGON NUT
54 165948 SCREW
55 165811 SUPPORT
56 165818 SUPPORT
57 165783 SUPPORT
58 165775 SUPPORT
59 165782 SUPPORT
60 4261 SCREW
61 5195 WASHER
62 4314 SCREW
63 165820 SPACER BUSH
64 5192 HEXAGON NUT
65 1072 SCREW
66 4272 SCREW
67 115753 SUPPORT
68 147106 SCREW
69 74218 FASTENING
70 4177 SCREW
71 165685 SUPPORT
72 165681 SUPPORT
73 165614 SUPPORT
74 165672 SUPPORT
75 4279 SCREW
76 163792 SPACER BUSH
77 4220 SCREW
78 4262 SCREW
79 36126 WASHER
80 5151 HEXAGON NUT
81 4219 SCREW
82 5617 SCREW
85 194111 BRACKET
86 194110 BRACKET
87 192359 FASTENING
88 4223 SCREW
89 5941 SCREW
90 122121 SCREW
91 115828 PROTECTING CAP
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
