Каталог запасных частей к технике: WIRTGEN W1500. WATER FILLING PUMP - HYDRAULIC
1
1
2
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
21
22
23
24
25
26
27
28
29
30
31
32
32
32
33
34
35
36
37
38
39
40
41
42
43
44
45
45
46
47
47
48
48
49
50
50
51
52
53
54
54
55
56
57
57
58
58
59
60
61
61
62
62
63
64
65
66
67
68
69
70
71
72
73
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 17405 | CONNECTION PIECE | |
| 2 | 3305 | HOSE CLAMP | |
| 3 | 4949 | COOLING-WATER HOSE | |
| 4 | 8099 | ANGLE | |
| 5 | 34979 | WATER PUMP | |
| 6 | 58076 | PUMP HOUSING | |
| 7 | 58077 | WHEEL | |
| 8 | 58078 | VALVE | |
| 9 | 58079 | SET OF SEALS | |
| 10 | 5147 | PLUG | |
| 11 | 5602 | ANGLE | |
| 12 | 40122 | HEX NIPPLE, REDUCING | |
| 13 | 7166 | BALL-CLOSURE COCK | |
| 14 | 9530 | WELD-ON CONNECTOR | |
| 15 | 15515 | ANGLE | |
| 16 | 37907 | COUPLING | |
| 17 | 15526 | COUPLING | |
| 18 | 13001 | HOSE COUPLING | |
| 19 | 4265 | SCREW | |
| 20 | 5195 | WASHER | |
| 21 | 5192 | HEXAGON NUT | |
| 22 | 128740 | COUPLING | |
| 23 | 104237 | TOOTHED RING | |
| 24 | 5162 | HEXAGON NUT | |
| 25 | 128735 | CONSOLE | |
| 26 | 4258 | SCREW | |
| 27 | 128737 | CLUTCH PROTECTOR | |
| 28 | 4219 | SCREW | |
| 29 | 5269 | HEXAGON NUT | |
| 30 | 132585 | SUPPORT | |
| 31 | 4181 | SCREW | |
| 32 | 5206 | WASHER | |
| 33 | 5209 | HEXAGON NUT | |
| 34 | 134225 | HYDRAULIC MOTOR | |
| 35 | 158564 | SET OF SEALS | |
| 36 | 18363 | DISK SPRING | |
| 37 | 4370 | SCREW | |
| 38 | 7257 | ANGLE FLANGE SCREWING | |
| 39 | 10917 | O-RING SEAL | |
| 40 | 10895 | SCREW | |
| 41 | 6078 | SCREW | |
| 42 | 6404 | ANGLE FLANGE SCREWING | |
| 43 | 37207 | REDUCING COUPLING | |
| 44 | 20984 | HYDRAULIC HOSE | |
| 45 | 3929 | ADJ.MALE STUD TEE-STUD BARREL | |
| 46 | 15605 | HYDRAULIC HOSE | |
| 47 | 1681 | HYDRAULIC HOSE | |
| 47 | 49470 | HYDRAULIC HOSE | |
| 48 | 49225 | HYDRAULIC HOSE | |
| 48 | 1676 | HYDRAULIC HOSE | |
| 49 | 40411 | THROTTLE CONNECTOR | |
| 50 | 1126 | MALE STUD COUPLING | |
| 51 | 9922 | SCREWED SEALING PLUG | |
| 52 | 3406 | CONNECTION PLATE | |
| 53 | 65969 | DIRECTIONAL VALVE | |
| 54 | 114160 | SOLENOID | |
| 55 | 114161 | SET OF SEALS | |
| 56 | 5495 | SCREW | |
| 57 | 131097 | FEMALE PLUG | |
| 58 | 21041 | SEAL | |
| 59 | 99749 | RUBBER HOSE | |
| 60 | 11538 | PVC HOSE | |
| 61 | 53780 | HOSE CLAMP | |
| 62 | 11439 | HOSE COUPLING | |
| 63 | 13002 | SUCTION BASKET | |
| 64 | 41250 | SUPPORT | |
| 65 | 4180 | SCREW | |
| 66 | 1499 | MALE STUD COUPLING | |
| 67 | 31446 | CAP NUT | |
| 68 | 5971 | DUMMY PLUG | |
| 69 | 5944 | SCREW | |
| 70 | 5800 | WASHER | |
| 71 | 5810 | HEXAGON NUT | |
| 72 | 154948 | TENSIONER BELT | |
| 73 | 106808 | SHAFT SEAL |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
