Каталог запасных частей к технике: WIRTGEN W1500. SIDE PLATE LIFTING/LOWER

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
3
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
6
7
8
9
10
10
11
11
11
11
11
11
11
11
12
13
13
13
13
13
13
14
15
16
17
17
17
18
18
19
19
20
20
21
21
21
21
22
22
22
22
23
23
24
24
25
25
26
26
27
28
29
30
31
31
31
32
33
33
34
35
36
37
38
39
40
41
42
43
43
Позиция на иллюстрации Заводской номер детали Название детали
1 80674 HYDRAULIC HOSE
2 170592 HYDRAULIC HOSE
3 125059 HYDRAULIC HOSE
4 30243 MALE STUD COUPLING
5 2887 ADJ.MALE STUD TEE-STUD BARREL
6 187018 HYDRAULIC HOSE
7 113568 HYDRAULIC HOSE
8 169410 HYDRAULIC HOSE
9 164624 HYDRAULIC HOSE
10 2884 BULKHEAD COUPLING
11 2888 ADJUSTABLE MALE STUD ELBOW
12 5012 PRESSURE GAUGE
13 1126 MALE STUD COUPLING
14 1676 HYDRAULIC HOSE
15 49225 HYDRAULIC HOSE
16 133262 HYDRAULIC HOSE
17 3406 CONNECTION PLATE
18 41935 PRESSURE-RELIEF VALVE
19 144951 DIRECTIONAL VALVE
20 150107 DIRECTIONAL VALVE
21 21041 SEAL
22 131097 FEMALE PLUG
23 114131 DIRECTIONAL VALVE
24 114160 SOLENOID
25 114161 SET OF SEALS
26 177642 SOLENOID
27 110346 PRESSURE REDUCTION VALVE
28 14747 SET OF SEALS
29 9922 SCREWED SEALING PLUG
30 31428 ADJUSTABLE MALE STUD ELBOW
31 3929 ADJ.MALE STUD TEE-STUD BARREL
32 1499 MALE STUD COUPLING
33 139898 HYDRAULIC HOSE
34 108263 HYDRAULIC HOSE
35 19567 ADJUSTABLE EQUAL TEE
36 51005 STRAIGHT COUPLING
37 31500 EQUAL ELBOW
38 4959 PARALLE FEMALE STUD COUPLING
39 11179 SEALING RING
40 188581 HYDRAULIC HOSE
41 153196 HYDRAULIC HOSE
42 5492 SCREW
43 165544 SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
