Каталог запасных частей к технике: WIRTGEN W1500. DRUM BEARING FB1300/1500
1
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
28
29
30
31
32
33
34
35
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 162035 | MOVABLE BEARING | |
| 1 | 95594 | MOVABLE BEARING | |
| 2 | 92961 | COVER | |
| 3 | 92962 | PLATE | |
| 4 | 4222 | SCREW | |
| 5 | 4220 | SCREW | |
| 6 | 84803 | SCREWED SEALING PLUG | |
| 6 | 192799 | SCREWED SEALING PLUG | |
| 7 | 27190 | O-RING SEAL | |
| 8 | 37616 | LOCKING RING | |
| 9 | 21715 | SPHERICAL ROLLER BEARING | |
| 10 | 92960 | BEARING HOUSING | |
| 11 | 92820 | AXIAL FACE SEAL | |
| 12 | 92959 | BEARING SHAFT | |
| 13 | 35815 | SCREW | |
| 14 | 1105 | GREASING NIPPLE | |
| 15 | 11181 | CAP | |
| 16 | 40148 | O-RING SEAL | |
| 17 | 87709 | GEARBOX | |
| 18 | 18802 | O-RING SEAL | |
| 19 | 4678 | SCREW | |
| 20 | 52610 | FRONT BEARING | |
| 21 | 54152 | FRONT BEARING | |
| 22 | 52612 | INTERMEDIATE SHAFT | |
| 23 | 54153 | INTERMEDIATE SHAFT | |
| 24 | 4628 | SCREW | |
| 25 | 8338 | CLAMPING SLEEVE | |
| 26 | 67150 | V-BELT PULLEY | |
| 26 | 148639 | V-BELT PULLEY | |
| 27 | 4469 | SCREW | |
| 28 | 39994 | WASHER | |
| 29 | 70821 | CRANK | |
| 30 | 4631 | SCREW | |
| 31 | 46944 | SCREWED SEALING PLUG | |
| 32 | 49027 | SCREWED SEALING PLUG | |
| 33 | 187078 | ADAPTER | |
| 34 | 148578 | BEARING BUSH | |
| 35 | 4628 | SCREW |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
