Каталог запасных частей к технике: WIRTGEN W1500. DISCHARGE CONVEYOR - SLEWING
1
2
3
4
4
5
6
7
7
8
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
20
21
21
21
21
22
22
22
23
23
23
24
25
26
27
27
28
28
29
30
30
31
32
33
33
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 51489 | RUBBER BUFFER | |
| 2 | 5131 | WASHER | |
| 3 | 5151 | HEXAGON NUT | |
| 4 | 45450 | HYDRAULIC CYLINDER | |
| 5 | 18288 | FORK HEAD | |
| 6 | 6395 | SET OF SEALS | |
| 7 | 8939 | BOLT | |
| 8 | 9854 | SPLIT PIN | |
| 9 | 4359 | SCREW | |
| 10 | 4080 | WASHER | |
| 11 | 71354 | LOCKING RING | |
| 12 | 20345 | PIVOTING BEARING | |
| 13 | 47594 | WASHER | |
| 14 | 4998 | MALE STUD COUPLING | |
| 15 | 2888 | ADJUSTABLE MALE STUD ELBOW | |
| 16 | 113569 | HYDRAULIC HOSE | |
| 17 | 104266 | HYDRAULIC HOSE | |
| 18 | 42930 | BULKHEAD COUPLING | |
| 19 | 1105 | GREASING NIPPLE | |
| 20 | 11181 | CAP | |
| 21 | 1114 | MALE STUD COUPLING | |
| 22 | 31428 | ADJUSTABLE MALE STUD ELBOW | |
| 23 | 3929 | ADJ.MALE STUD TEE-STUD BARREL | |
| 24 | 19567 | ADJUSTABLE EQUAL TEE | |
| 25 | 20974 | HYDRAULIC HOSE | |
| 26 | 20976 | HYDRAULIC HOSE | |
| 27 | 142452 | HYDRAULIC HOSE | |
| 28 | 16033 | HYDRAULIC HOSE | |
| 29 | 1912 | BALL-CLOSURE COCK | |
| 30 | 73733 | THROTTLE CONNECTOR | |
| 31 | 143617 | BRAKE VALVE | |
| 32 | 114131 | DIRECTIONAL VALVE | |
| 33 | 114160 | SOLENOID | |
| 34 | 114161 | SET OF SEALS | |
| 35 | 58916 | SCREW | |
| 36 | 131097 | FEMALE PLUG | |
| 37 | 21041 | SEAL | |
| 38 | 58605 | PIPE CLIP | |
| 39 | 5206 | WASHER | |
| 40 | 12247 | HEXAGON NUT |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
