Каталог запасных частей к технике: WIRTGEN W1000L. BELT TENSIONER UNIT
1
2
2
3
4
5
6
7
8
9
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
19
19
19
19
20
21
22
23
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42
43
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 53031 | TENSIONER ARM | |
| 2 | 2473 | BEARING | |
| 3 | 102849 | SHAFT | |
| 4 | 9795 | LOCKING RING | |
| 5 | 8688 | GREASING NIPPLE | |
| 6 | 11181 | CAP | |
| 7 | 4421 | SCREW | |
| 8 | 57301 | HYDRAULIC CYLINDER | |
| 9 | 10481 | FORK HEAD | |
| 10 | 38870 | SET OF SEALS | |
| 11 | 34465 | BOLT | |
| 12 | 5849 | SPLIT PIN | |
| 13 | 3794 | BANJO COUPLING,ONE-PIECE BOLT | |
| 14 | 5047 | REDUCING COUPLING | |
| 15 | 3929 | ADJ.MALE STUD TEE-STUD BARREL | |
| 16 | 20975 | HYDRAULIC HOSE | |
| 17 | 2887 | ADJ.MALE STUD TEE-STUD BARREL | |
| 18 | 1645 | HYDRAULIC HOSE | |
| 19 | 2888 | ADJUSTABLE MALE STUD ELBOW | |
| 20 | 71367 | BALL-CLOSURE COCK | |
| 21 | 1641 | HYDRAULIC HOSE | |
| 22 | 1619 | HYDRAULIC HOSE | |
| 23 | 38476 | THROTTLE CONNECTOR | |
| 24 | 51005 | STRAIGHT COUPLING | |
| 25 | 3622 | MALE STUD COUPLING | |
| 26 | 1499 | MALE STUD COUPLING | |
| 27 | 7708 | DIAPHRAGM ACCUMULATOR | |
| 28 | 4646 | MEASURING CONNECTOR | |
| 29 | 71368 | NON-RETURN VALVE | |
| 30 | 5800 | WASHER | |
| 31 | 19744 | SCREW | |
| 32 | 72793 | ADJUSTING LEVER | |
| 33 | 5211 | WASHER | |
| 34 | 5799 | WASHER | |
| 35 | 5807 | SCREW | |
| 36 | 98503 | ALUMINIUM SIGN | |
| 37 | 5930 | MALE STUD COUPLING | |
| 38 | 4941 | MALE STUD COUPLING | |
| 39 | 2888 | ADJUSTABLE MALE STUD ELBOW | |
| 40 | 1641 | HYDRAULIC HOSE | |
| 41 | 42930 | BULKHEAD COUPLING | |
| 42 | 71354 | LOCKING RING | |
| 43 | 8318 | LOCKING RING |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
