11880104, 11891269 Stabilisers
Stabiliser cylinder
11891273, 11891109, 11891061 Excavator boom, extendible dipper arm
11891041, 11891524, 11891109, 11891061 Boom and dipper arm
Boom cylinder
Dipper arm cylinder
11891273 Extendible dipper cylinder
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
VOE 11887060
Square Tube
2
VOE 11890229
Pad
3
VOE 11885475
Foot Plate
4
VOE 11885283
Pin
5
VOE 11887730
Pin
6
VOE 11883349
Wear Part
7
VOE 11887740
Plate
8
VOE 963111
Lock nut
9
VOE 967562
Snap ring
10
VOE 11890115
Washer
11
Cylinder
Cylinder
12
VOE 11886020
Pad
13
VOE 13965195
Screw
14
VOE 971099
Flange Lock Nut
15
Sealing ring
Sealing ring
16
VOE 914470
Snap Ring
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
