Extendible dipper cylinder 11891417
VOE13960141
1
2
3
4
5
6
7
8
9
9
10
11
12
13
14
15
16
Позиция на иллюстрации
Заводской номер детали
Название детали
VOE13960141
VOE13960141
Washer
1
VOE11203562
Side Panel
1
VOE11203560
Side Panel
2
VOE11204407
Cover
3
VOE11201200
Plastic Rivet
4
VOE11201200
Plastic Rivet
5
VOE11884733
Panel
5
VOE11202713
Panel
6
VOE11204417
Front Panel
6
VOE11204415
Front Panel
7
StorageTray
Storage Tray
8
StorageTray
Storage Tray
9
VOE11200973
Plug
10
VOE969589
6-pt skt screw
11
VOE960139
Washer
12
VOE949921
Spring Nut
13
VOE11057786
Plug
14
VOE13945444
Flange screw
15
VOE11202229
Attachment
16
VOE975378
Screw
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
