VOE24425842
1
2
3
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Позиция на иллюстрации
Заводской номер детали
Название детали
VOE20791246
VOE20791246
Cylinder Block
VOE24425842
VOE24425842
Crankcase
1
VOE20460006
Screw
2
VOE20460001
Bushing
3
VOE20460000
Plug
4
VOE13969011
Gasket
5
VOE20405717
Plug
6
VOE20405719
Plug
7
VOE20508600
Plug
8
VOE20405716
Plug
9
VOE20508605
Plug
10
VOE20459999
Cmshft Bushing
11
VOE20459998
Cmshft Bushing
12
VOE20405721
Hood
13
VOE20412745
Core Plug
14
VOE20405584
Guide Sleeve
15
VOE888289
Hexagon screw
16
VOE24426064
Cover
17
VOE20412359
Sealing ring
18
VOE20441859
Plug
19
VOE13947281
Gasket
20
VOE20405716
Plug
21
VOE13947621
Plane Gasket
22
VOE20459899
Screw
23
VOE20459900
Sealing ring
24
VOE20412745
Core Plug
25
VOE20450778
Core Plug
26
VOE13947281
Gasket
27
VOE20441859
Plug
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
