VOE 11712879
VOE 11712881
VOE 11712883
VOE 11712884
VOE 11712880
1
2
3
3
4
4
5
6
7
8
9
Позиция на иллюстрации
Заводской номер детали
Название детали
VOE 11712879
VOE 11712879
Direction Valve
VOE 11712881
VOE 11712881
Direction Valve
VOE 11712883
VOE 11712883
Direction Valve
VOE 11712884
VOE 11712884
Direction Valve
VOE 11712880
VOE 11712880
Compensator
1
VOE 11988526
Press Regulator
2
VOE 11988527
Check valve
3
VOE 11988532
Relief valve
4
VOE 11988541
Sealing Kit
5
VOE 11715275
Control
6
VOE 11712580
Bellows Kit
7
VOE 11988529
Control
8
VOE 11988538
Sealing Kit
9
VOE 11712579
Sealing Kit
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
