VOE 11712895
1
2
3
3
4
4
5
6
7
8
Позиция на иллюстрации
Заводской номер детали
Название детали
VOE 11712895
VOE 11712895
Direction Valve
1
VOE 11988526
Press Regulator
2
VOE 11988527
Check valve
3
VOE 11988532
Relief valve
4
VOE 11988541
Sealing Kit
5
VOE 11715275
Control
6
VOE 11712580
Bellows Kit
7
VOE 11712905
Control
8
VOE 11988538
Sealing Kit
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
