Hydraulic cylinder 11891079, 11891080
Hydraulic cylinder 11891079, 11891080
Swing system
Boom swing system
Swing cylinder
Lock cylinder
Stabilisers
Stabiliser cylinder
Foot plate
Excavator boom, exendible dipper arm 11890342
Boom and dipper arm 11890343
Boom cylinder 11890342, 11890343
Dipper arm cylinder 11890342, 11890343
Bucket cylinder 11890342, 11890343
Extendible dipper cylinder 11890342
VOE 11881974
VOE 11712746
VOE 11881973
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Позиция на иллюстрации
Заводской номер детали
Название детали
VOE 11881974
VOE 11881974
Cylinder
VOE 11712746
VOE 11712746
Sealing Kit
VOE 11881973
VOE 11881973
Cylinder
1
VOE 11988262
Piston rod
2
O-ring
O-ring
3
Scraper
Scraper
4
VOE 11712744
Piston rod guide
5
Guide Ring
Guide Ring
6
Piston Rod Seal
Piston Rod Seal
7
Lock Ring
Lock Ring
8
Back-up ring
Back-up ring
9
O-ring
O-ring
10
VOE 11712745
Piston
11
Screw
Screw
12
Piston seal
Piston seal
13
Guide Ring
Guide Ring
14
O-ring
O-ring
15
Cylinder tube
Cylinder tube
16
VOE 11711136
Bushing
17
VOE 11988263
Bushing
18
VOE 11709664
Lub Nipple
19
Scraper
Scraper
20
VOE 11883675
Scraper
