Позиция на иллюстрации
Заводской номер детали
Название детали
1
2087037
SPRAY BAR
2
2087038
HOOD
3
9510200933
SCREW
4
9500100125
WASHER
5
2086917
ADAPTER
6
9650720062
O-RING
7
2086918
NOZZLE 10
8
2087041
CONNECTING PIPE
9
9603220057
SCREW
10
2087039
CONSOLE
11
2086653
CLAMP
12
9506320912
SCREW
13
2147213
NOZZLE 16
14
2147214
NOZZLE 7
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
