Каталог запасных частей к технике: VOGELE SUPER 1800-2SJ. COOLING SYSTEM
2
2
2
3
3
3
3
3
4
4
4
5
5
6
6
6
7
8
9
10
11
11
11
11
12
13
13
13
13
13
13
13
13
13
13
14
15
16
16
16
16
17
18
19
19
20
21
21
21
22
22
23
23
25
25
27
27
28
29
30
31
32
33
34
35
36
37
38
39
39
39
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 2 | 4611602146 | RUBBER BEARING | |
| 3 | 9500100125 | WASHER | |
| 4 | 9500100934 | NUT | |
| 5 | 9510200933 | SCREW | |
| 6 | 9510380931 | SCREW | |
| 7 | 2000201 | HOSE | |
| 8 | 2001474 | SHEET | |
| 9 | 2048181 | COOLANT HOSE | |
| 10 | 2060277 | SHEET | |
| 11 | 2012382 | PIPE CLIP | |
| 12 | 9500080125 | WASHER | |
| 13 | 9508160933 | SCREW | |
| 14 | 2000160 | JOINING PIECE | |
| 15 | 2060657 | SEAL | |
| 16 | 4604042224 | SEALING | |
| 17 | 2048434 | SHEET | |
| 18 | 2048243 | SHEET | |
| 19 | 4618802047 | HOSE | |
| 20 | 2003828 | PLUG | |
| 21 | 9510123017 | HOSE CLAMP | |
| 22 | 2066325 | INTERCOOLER | |
| 23 | 2066332 | HYDRAULIC OIL COOLER | |
| 25 | 2066333 | HOOD | |
| 27 | 2008576 | LID | |
| 28 | 3506031014 | COOLANT | |
| 29 | 4618372086 | PIPE CLIP | |
| 30 | 2084352 | COMBINED COOLER | |
| 31 | 2084354 | WATER COOLER | |
| 32 | 2084355 | SURGE TANK | |
| 33 | 2084368 | HOSE | |
| 34 | 2084372 | HOSE | |
| 35 | 2084542 | HOSE | |
| 36 | 2084545 | HOSE FITTING | |
| 37 | 2085227 | SIGHT GLASS | |
| 38 | 9510160933 | SCREW | |
| 39 | 2084360 | SHEET |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
