1
2
3
4
5
6
7
8
9
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
9654131000
VALVE BLOCK SCREED ON / OFF
2
9508370912
SCREW
3
9653951008
VALVE
4
2002893
PRESSURE RELIEF VALVE
5
9625551000
SCREW COUPLING
6
2009465
HYDRAULIC BLOCK
7
9653991004
SCREW KIT
8
9603140057
SCREW
9
9603180057
SCREW
10
9637220057
SCREW
11
9653951014
SET OF SEALS
12
9653971011
SET OF SEALS
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
