Каталог запасных частей к технике: VOGELE SUPER 1800-2. PUMP DISTRIBUTION REDUCER
1
2
4
6
7
9
10
11
12
14
15
16
17
18
20
22
23
25
28
30
34
34
35
35
36
37
38
39
40
41
42
44
45
46
47
48
50
51
54
55
56
57
58
59
60
61
62
63
64
65
66
68
69
70
71
72
73
74
75
76
77
78
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 2008799 | HOUSING | |
| 2 | 2008806 | HOUSING | |
| 4 | 2008807 | BEARING CAP | |
| 6 | 2008809 | WAVE | |
| 7 | 2008810 | DRIVE SHAFT | |
| 9 | 2008819 | PIPE | |
| 10 | 2008820 | PIPE | |
| 11 | 2008828 | PIPE | |
| 12 | 2008830 | PIPE | |
| 14 | 2008831 | SPROCKET | |
| 15 | 2008832 | SPUR WHEEL | |
| 16 | 2008861 | SPUR WHEEL | |
| 17 | 2008862 | SPUR WHEEL | |
| 18 | 2008863 | SPUR WHEEL | |
| 20 | 2008864 | SCREW | |
| 22 | 2008865 | BOLT | |
| 23 | 2008866 | BOLT | |
| 25 | 2008867 | RIFLE | |
| 28 | 2008870 | DISC | |
| 30 | 2008872 | V-BELT PULLEY | |
| 34 | 2008877 | GROOVE BALL BEARINGS | |
| 35 | 2008878 | GROOVE BALL BEARINGS | |
| 36 | 2008879 | CYLINDER ROLLER BEARING | |
| 37 | 2032212 | CYLINDER ROLLER BEARINGS | |
| 38 | 2008902 | OIL SEAL | |
| 39 | 2008903 | O-RING | |
| 40 | 2008904 | O-RING | |
| 41 | 2008905 | O-RING | |
| 42 | 9690870062 | O-RING | |
| 44 | 9500300472 | SEEGER RING | |
| 45 | 9500450471 | SEEGER RING | |
| 46 | 9500600471 | SEEGER RING | |
| 47 | 9501100472 | SEEGER RING | |
| 48 | 2008940 | SUPPORT DISC | |
| 50 | 2008942 | ADJUSTING SPRING | |
| 51 | 2008943 | ADJUSTING SPRING | |
| 54 | 2008945 | CLAMPING SLEEVE | |
| 55 | 9508330912 | SCREW | |
| 56 | 9510207984 | SCREW | |
| 57 | 9510320912 | SCREW | |
| 58 | 9510440912 | SCREW | |
| 59 | 2008950 | SCREW | |
| 60 | 2008953 | THREADED PIN | |
| 61 | 2008956 | PUMP | |
| 62 | 2032214 | ANGLED SCREW-IN SCREW | |
| 63 | 2008958 | SCREW | |
| 64 | 2029604 | SWIVEL COUPLING | |
| 65 | 2008960 | SCREW | |
| 66 | 2008961 | SCREW | |
| 68 | 9515220910 | SCREW | |
| 69 | 9515300910 | SCREW | |
| 70 | 2009049 | SCREW | |
| 71 | 2009050 | FILTER | |
| 72 | 2009051 | OIL LEVEL INDICATOR | |
| 73 | 9521217603 | SEAL RING | |
| 74 | 9511137603 | SEAL RING | |
| 75 | 9515137603 | SEAL RING | |
| 76 | 2009052 | SEAL RING | |
| 77 | 2009056 | SEAL RING | |
| 78 | 2014510 | LID: WITHOUT HIGH COMPRESSION |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
