Позиция на иллюстрации
Заводской номер детали
Название детали
1
4618270029
CRANK
2
2014120
PIPE
3
4607132057
ARTICULATED HEAD
4
4607132058
ARTICULATED HEAD
5
9500300471
SEEGER RING
6
9520300439
NUT
7
2006559
SHEET
8
9508250933
SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
