Позиция на иллюстрации
Заводской номер детали
Название детали
1
4611402214
BEARING BRACKET RE.
2
9516320933
SCREW
3
9501707349
WASHER
4
4611402200
STOCK PART
5
4602022624
BOLT
6
4618042845
DISC
7
9522074361
NUT
8
4604132633
LOCKING LID
9
9510250915
THREADED PIN
10
9501000472
SEEGER CIRCLIP RING
11
4617212483
DISTANCE RING
12
4604112142
POETRY
13
9541110635
PENDULUM BEARING
14
4604132602
LOCKING LID
15
4610230116
CLAMPING PART
16
9510440931
SCREW
17
9500100934
NUT
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
