Позиция на иллюстрации
Заводской номер детали
Название детали
1
9603110057
SCREW CONNECTION
2
2009127
HOSE
3
9630120057
SCREW CONNECTION
4
9625531000
CONNECTOR FOR MEASUREMENT
5
9612271020
DIRECTIONAL VALVE
6
2005334
PIPE
7
9627120057
SCREW CONNECTION
8
2005335
PIPE
9
9629120057
SCREW CONNECTION
10
9618220060
SCREW
11
9520803902
SCREW
12
2009126
HOSE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
