Позиция на иллюстрации
Заводской номер детали
Название детали
1
2076194
SHEET
2
9516340933
SCREW
3
9501707349
WASHER
4
9500160934
NUT
5
2081197
SHEET
6
9508200933
SCREW
7
9500080125
WASHER
8
2081883
TOOL BOX CPL.
9
2062594
SHEET
10
2089677
HOLDER
11
9650350185
PAIR OF CLAMPING HALVES
12
9680050185
TOP COVER
13
9506330933
SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
