Позиция на иллюстрации
Заводской номер детали
Название детали
1
9628251000
HY PUMP
2
9628071001
SEAL KIT
3
9630580062
O-RING SEAL
4
2055691
SCREW
5
9612991107
SCREW
6
9612221020
SCREW CONNECTION
7
9602280057
SCREW CONNECTION
8
9618660060
SCREW
9
9603180057
SCREW
10
2049802
HOSE
11
2004458
HOSE
12
2004462
HOSE
13
2049750
HOSE
14
3450022045
HOSE
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
