Каталог запасных частей к технике: VOGELE SUPER 1300-3. CONTROL BOX:CONTROL UNIT
10
11
12
13
13
14
15
16
20
20
30
31
31
32
33
33
34
40
41
42
43
50
60
70
70
80
81
82
130
130
130
130
330
450
600
610
620
630
640
650
660
670
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 2254009 | CIRCUIT BOARD | |
| 11 | 9505100084 | SCREW | |
| 12 | 9505160084 | SCREW | |
| 13 | 9510516798 | SERRATED LOCK WASHER | |
| 14 | 2227224 | FLAT WASHER | |
| 15 | 2227222 | FLAT WASHER | |
| 16 | 4607092068 | THREADED SLEEVE | |
| 20 | 2231923 | MODULE 24V | |
| 30 | 2543302 | SCREW | |
| 31 | 9500060125 | WASHER | |
| 32 | 2543226 | CONTACT WASHER | |
| 33 | 2543262 | NUT | |
| 34 | 2543248 | SPRING RING | |
| 40 | 2033278 | PROTECTIVE CAP | |
| 41 | 9500080125 | WASHER | |
| 42 | 9510846798 | SERRATED LOCK WASHER | |
| 43 | 9500080934 | NUT | |
| 50 | 3515116011 | END PLATE | |
| 60 | 3515116003 | CLAMP | |
| 70 | 3515116030 | RELAY TERMINAL | |
| 80 | 2246126 | CAN NODE | |
| 81 | 9504200084 | SCREW | |
| 82 | 9500040125 | WASHER | |
| 130 | 3515110084 | TERMINAL | |
| 330 | 2272636 | PLUG-IN JUMPER | |
| 450 | 3515116024 | CROSS CONNECTION | |
| 600 | 2027272 | FUSE | |
| 610 | 3515160307 | FUSE 32V | |
| 620 | 3515160310 | FUSE | |
| 630 | 3515160315 | FUSE 32V | |
| 640 | 3515160325 | FUSE 32V | |
| 650 | 2053004 | RELAY | |
| 660 | 2003910 | RELAY | |
| 670 | 2188971 | DIODE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
