Каталог запасных частей к технике: VOGELE SUPER 1300-3. AUGER SHAFT WITH BEARING
10
11
11
20
21
22
30
31
32
40
40
40
41
41
41
42
42
50
50
50
51
51
51
52
52
60
61
61
62
80
81
81
82
90
91
91
100
101
101
110
110
120
130
140
150
160
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 2263138 | AUGER SHAFT | |
| 11 | 9508200912 | SCREW | |
| 20 | 2263126 | BEARING BLOCK, LEFT SIDE | |
| 21 | 9512300933 | SCREW | |
| 22 | 9500130125 | WASHER | |
| 30 | 2263131 | BEARING BLOCK, RIGHT SIDE | |
| 31 | 9512300933 | SCREW | |
| 32 | 9500130125 | WASHER | |
| 40 | 2003451 | AUGER BLADE, LEFT SIDE | |
| 41 | 9516380931 | SCREW | |
| 42 | 9500161587 | CAP NUT | |
| 50 | 2003452 | AUGER BLADE, RIGHT SIDE | |
| 51 | 9516380931 | SCREW | |
| 52 | 9500161587 | CAP NUT | |
| 60 | 2274862 | PAD PLATE | |
| 61 | 9516400931 | SCREW | |
| 62 | 9500161587 | CAP NUT | |
| 80 | 9541110635 | PENDULUM BEARING | |
| 81 | 2263212 | DISTANCE RING | |
| 82 | 2263213 | LOCKING-L-RING | |
| 90 | 2274469 | LID | |
| 91 | 9510250915 | THREADED PIN | |
| 100 | 2263214 | LID | |
| 101 | 9510250915 | THREADED PIN | |
| 110 | 2263215 | NILOS RING | |
| 120 | 9636970062 | O-RING SEAL | |
| 130 | 9690370062 | O-RING SEAL | |
| 140 | 9604100057 | CUTTING RING | |
| 150 | 9688100058 | SCREW CONNECTION | |
| 160 | 9601580054 | GREASING NIPPLE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
