10
20
30
40
50
50
60
Позиция на иллюстрации
Заводской номер детали
Название детали
10
2235661
VALVE BLOCK
20
2251198
VALVE
30
9505300912
SCREW
40
2251280
NOZZLE
50
9602070057
SCREW CONNECTION
60
9602120057
SCREW CONNECTION
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
