10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
10
2305418
LEVER
11
2051668
WASHER
12
9512200933
SCREW
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
