Каталог запасных частей к технике: VOGELE SUPER 1100-3. 24 V POWER SUPPLY BATTERY
21
22
23
24
30
35
40
50
50
60
61
62
62
63
64
70
71
80
90
91
92
120
120
125
130
140
150
155
155
160
160
161
162
165
170
180
190
200
210
220
230
231
232
240
241
241
242
242
500
510
520
530
540
550
560
570
580
590
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 21 | 2544118 | SCREW | |
| 22 | 2543289 | WASHER | |
| 23 | 2543237 | CONTACT WASHER | |
| 24 | 2543257 | SPRING RING | |
| 30 | 2135021 | CABLE | |
| 35 | 2032353 | DUMMY PLUG | |
| 40 | 3515018715 | PLUG SOCKET 24V | |
| 50 | 2289899 | PROTECTIVE CAP | |
| 60 | 2123413 | PLC-CONTROL | |
| 61 | 2285011 | DISTANCE TUBE | |
| 62 | 9500060125 | WASHER | |
| 63 | 9500060934 | NUT | |
| 64 | 9506330933 | SCREW | |
| 70 | 2300355 | HOLDER | |
| 71 | 2300364 | HOLDER | |
| 80 | 2063814 | CABLE | |
| 90 | 2193701 | RELAY | |
| 91 | 9506120933 | SCREW | |
| 92 | 9500060125 | WASHER | |
| 120 | 2054323 | BATTERY | |
| 125 | 2054634 | RUBBER | |
| 130 | 2055436 | BATTERY COVERING | |
| 140 | 2232665 | BATTERY CABLE | |
| 150 | 2232701 | BATTERY COVERING | |
| 155 | 2441627 | PROTECTIVE CAP | |
| 160 | 2141568 | FUSE HOLDER | |
| 161 | 9506120933 | SCREW | |
| 162 | 9500060125 | WASHER | |
| 165 | 2141600 | BUSBAR | |
| 170 | 2141587 | FUSE | |
| 180 | 2189659 | FUSE | |
| 190 | 2189732 | BLADE FUSE | |
| 200 | 9500080934 | NUT | |
| 210 | 9500080125 | WASHER | |
| 220 | 2048152 | BLIND CAP | |
| 230 | 2285024 | COVER SHEET | |
| 231 | 9500847349 | WASHER | |
| 232 | 9508200933 | SCREW | |
| 240 | 2298984 | METAL PLATE | |
| 241 | 9500647349 | WASHER | |
| 242 | 9506160933 | SCREW | |
| 500 | 2302399 | CABLE | |
| 510 | 2302431 | CABLE | |
| 520 | 2208201 | CABLE | |
| 530 | 2281876 | CABLE | |
| 540 | 2214526 | BATTERY CABLE | |
| 550 | 2302441 | CABLE | |
| 560 | 2302426 | CABLE | |
| 570 | 2302436 | CABLE | |
| 580 | 2302439 | CABLE | |
| 590 | 2302444 | CABLE |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
