Каталог запасных частей к технике: VOGELE AB500-3 TV. VSS_BASIC SCREED TV
10
20
30
40
50
50
50
60
60
60
70
70
80
80
90
90
100
100
110
120
130
140
150
150
160
170
170
170
170
180
180
190
190
200
210
220
230
240
240
240
250
250
250
250
260
280
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 2202733 | TAMPER BAR, LEFT SIDE | |
| 20 | 2202847 | TAMPER BAR, RIGHT SIDE | |
| 30 | 2202970 | TAMPER BAR, LEFT SIDE | |
| 40 | 2203022 | TAMPER BAR, RIGHT SIDE | |
| 50 | 2035050 | HEATING ROD | |
| 60 | 9603189305 | FLAT STEEL | |
| 70 | 4602416482 | COVER PLATE, LEFT SIDE | |
| 80 | 4602416483 | COVER PLATE, RIGHT SIDE | |
| 90 | 4608512649 | SUPPORT, LEFT SIDE | |
| 100 | 4608512648 | SUPPORT, RIGHT SIDE | |
| 110 | 2201289 | SCREED PLATE, LEFT SIDE | |
| 120 | 2201290 | SCREED PLATE, RIGHT SIDE | |
| 130 | 2202435 | SCREED PLATE, LEFT SIDE | |
| 140 | 2202445 | SCREED PLATE, RIGHT SIDE | |
| 150 | 2042576 | INSULATING PLATE | |
| 160 | 2042577 | INSULATING PLATE | |
| 170 | 4608112101 | SLEEVE | |
| 180 | 2035986 | HEATING ROD | |
| 190 | 2035992 | HEATING ROD | |
| 200 | 2042687 | INSULATION PLATE | |
| 210 | 2042688 | INSULATION PLATE | |
| 220 | 2042689 | INSULATION PLATE | |
| 230 | 2042690 | INSULATION PLATE | |
| 240 | 2201295 | WEARING BAR | |
| 250 | 2027338 | STRIP STEEL | |
| 260 | 2310743 | MOUNTING MATERIAL | |
| 280 | 2310096 | VSS_BASIC SCREED TV |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
