Каталог запасных частей к технике: Shantui SL-50W. MAIN TRANSMISSION ASSEMBLY (370801)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
16
17
17
18
19
20
21
22
23
24
25
26
27
27
28
28
29
29
30
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 461-18-01000 | 461-18-01000 | Main transmission assy | |
| 1 | 461-18-01001 | Lock nut | |
| 2 | 461-18-01002 | Washer | |
| 3 | 461-18-01032 | O-seal ring | |
| 4 | 461-18-01101 | Flange | |
| 5 | GB5785 | Bolt | |
| 6 | 01602-21236 | Рессорная шайба | |
| 7 | GB13871 | Oil seal | |
| 8 | GB13871 | Oil seal | |
| 9 | 461-18-01003 | Sealing gland | |
| 10 | GB297 | Bearing | |
| 11 | 461-18-01004 | Bearing bushing | |
| 12 | 461-18-01005/6/7 | Adjusting washer | |
| 13 | 461-18-01008 | Shaft bushing | |
| 14 | GB297 | Bearing | |
| 15 | 461-18-01029/30/31 | Adjusting washer | |
| 16 | 461-18-01025 | Adjusting nut | |
| 17 | Inch47686/47620A | Bearing | |
| 18 | 461-18-01021 | Differential bolt | |
| 19 | 461-18-01016 | Nut | |
| 20 | 461-18-01015 | Differential cage | |
| 21 | 461-18-01018 | Driven bevel gear | |
| 22 | 461-18-01017 | Bolt | |
| 23 | 461-18-01019 | Washer for bevel gear | |
| 24 | 461-18-01028 | Differential crossing | |
| 25 | 461-18-01020 | Bevel gear | |
| 26 | 461-18-01023 | Bearing seat | |
| 27 | 461-18-01013 | Bolt | |
| 28 | 461-18-01009 | Lock plate | |
| 29 | 01602-21030 | Шайба | |
| 30 | 01014-81020 | Bolt | |
| 31 | 461-18-01014 | Iron wire | |
| 32 | 461-18-01022 | Nut | |
| 33 | 461-18-01026 | Differential cage | |
| 34 | 461-18-01012 | Thrust washer | |
| 35 | 461-18-01027 | Axle shaft gear | |
| 36 | 461-18-01011 | Differential cage | |
| 37 | 461-18-01200 | Bolt | |
| 38 | 461-18-01024 | Lock plate | |
| 39 | GB6173M27X2 | Nut | |
| 40 | NJ2307ENVX3 | Bearing | |
| 41 | GB30590/96.5 | Stop ring | |
| 42 | 461-18-01010 | Driving bevel gear | |
| 43 | 01602-21442 | Рессорная шайба | |
| 44 | 01050-51455 | Bolt |
