INSTRUMENT DESK (Xuzhou SIDA)
INSTRUMENT DESK (Jiangsu HUACHENG)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Позиция на иллюстрации
Заводской номер детали
Название детали
1
D2540-04702
Wiper switch
2
D2541-14802
Fan/warm braw switch
3
D2542-00202
Work lamp switch
4
D2511-08700
Small lamp and top lamp switch
5
D2544-14802
Far and near beam for front lamp
6
D2545-00202
Rear lamp switch
7
D2910-25500
Control flexible shaft
8
D2121-14001
Oil temperature meter, torque converter
9
D2171-00000
Man-hour meter
10
D2163-03200
Shift gears pressure meter
11
D2140-03200
Вольтметр
12
D2460-00000
Far indicator light for headlight
13
D2461-00000
Left steering indicator light
14
D2462-00000
Power indicator light
15
D2463-00000
Right steering indicator light
16
D2464-00000
Brake indicator light
17
D2103-01000
Oil pressure meter for engine
18
D2190-01200
Air pressure meter
19
D2113-12000
Water temperature for engine
20
D2510-05001
Critical button switch
21
D2560-00001
Combined switch
22
D2763-02001
Fuse box
23
D2500-41201
Start switch
24
D2780-00001
Reserve power
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
