Каталог запасных частей к технике: Shantui SL-50W. GEARBOX CONTROL VALVE PART 4WG180
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
340
350
360
370
380
400
410
460
470
480
490
500
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 10 | 4642306152 | Valve Body | |
| 20 | 4620306248 | Locking Plate | |
| 30 | 732040838 | Spring | |
| 40 | 4620306245 | Spool | |
| 50 | 732040837 | Spring | |
| 60 | 730061778 | Sleeve | |
| 70 | 769120747 | Gasket | |
| 80 | 4620306247 | Bush | |
| 90 | 4642306094 | Spool | |
| 100 | 732041254 | Spring | |
| 110 | 4620306252 | Backing Pin | |
| 120 | 634303118 | O-Ring | |
| 130 | 4620306413 | Spool | |
| 140 | 732041390 | Spring | |
| 150 | 4620306414 | Spool | |
| 160 | 4644306549 | Backing Pin | |
| 170 | 4644306241 | Mounted Plate | |
| 180 | 4620306255 | Spool | |
| 190 | 732041154 | Spring | |
| 200 | 732041254 | Spring | |
| 210 | 4642306093 | Spool | |
| 220 | 4620306252 | Backing Pin | |
| 230 | 634303118 | O-Ring | |
| 240 | 4642306049 | Gasket | |
| 250 | 4644306549 | Backing Pin | |
| 260 | 732041254 | Spring | |
| 270 | 4642306095 | Spool | |
| 280 | 732041254 | Spring | |
| 290 | 4642306096 | Spool | |
| 300 | 4620306252 | Backing Pin | |
| 310 | 634303118 | O-Ring | |
| 320 | 4620306415 | Cover | |
| 330 | 4620306479 | Paper Washer | |
| 340 | 636015244 | Bolt | |
| 350 | 501315338 | Magnetic Valve | |
| 360 | 636101129 | Bolt | |
| 370 | 630305012 | Washer | |
| 380 | 4620206019 | Cable Unit | |
| 400 | 636404299 | Bolt | |
| 410 | 630302076 | Washer | |
| 460 | 4620306259 | Magnetic Valve Encloser | |
| 470 | 634303951 | O-Ring | |
| 480 | 4620306241 | Arch Clip | |
| 490 | 636304019 | Plug Screw | |
| 500 | 634801152 | Red Copper Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
