Каталог запасных частей к технике: Shantui Погрузчик SF50/SF60/SF70. REDUCTION AND DIFFERENTIAL
1
4
4
5
6
7
8
10
11
11
12
13
14
15
16
17
18
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| C50KD000 | C50KD000 | Differential unit | |
| 1 | C50KD001 | Bolt | |
| 4 | C50KD003 | The differential case | |
| 4 | C50KD002 | The differential case | |
| 5 | C50KD004 | Differential assembly | |
| 6 | C50KD005 | Adjusting nut | |
| 7 | C50KD006 | Differential bearing | |
| 8 | C50KD007 | Bolt | |
| 10 | C50KD008 | Nut | |
| 11 | C50KD009 | Driving gear | |
| 11 | C50KD010 | The driven gear | |
| 12 | C50KD011 | Thrust washer | |
| 13 | C50KD012 | Half axle gear | |
| 14 | C50KD013 | Planetary gear shaft | |
| 15 | C50KD014 | Planet gear | |
| 16 | C50KD015 | Planetary gear pad | |
| 17 | C50KD016 | Bolt | |
| 18 | C50KD017 | The adjusting nut lock | |
| 18 | C50KD018 | The adjusting nut lock | |
| 19 | C50KD019 | Bolt | |
| 20 | C50KD020 | The main reducer shell assembly | |
| 21 | C50KD021 | Nut | |
| 22 | C50KD022 | The elastic washer | |
| 23 | C50KD023 | Guide bearing clip | |
| 24 | C50KD024 | Clip bolt | |
| 25 | C50KD025 | The spring retainer | |
| 26 | C50KD026 | The driving gear guide bearing | |
| 27 | C50KD027 | The active gear bearing | |
| 28 | C50KD028 | Spacer sleeve | |
| 29 | C50KD029 | The adjusting shim | |
| 30 | C50KD030 | The adjusting shim | |
| 31 | C50KD031 | Pinion bearing seat | |
| 32 | C50KD032 | Outer bearing driving gear | |
| 33 | C50KD033 | The driving gear oil seal | |
| 34 | C50KD034 | Pinion flange assembly | |
| 35 | C50KD035 | Collar nut | |
| 36 | C50KD036 | The elastic washer | |
| 37 | C50KD037 | Bolt | |
| 38 | C50KD038 | Reducer bearing cover | |
| 39 | C50KD039 | The main reducer shell | |
| 40 | C50KD040 | O ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
