Каталог запасных частей к технике: Shantui Погрузчик SF30. TORQUE CONVERTER TRANSMISSION ASSY (1/8)
1
1
2
3
4
4
5
6
7
8
9
9
10
10
11
11
11
12
13
14
15
16
17
17
17
17
18
19
20
21
21
22
23
24
25
26
27
28
28
29
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
49
50
51
52
53
54
55
56
58
59
60
61
62
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | YDS30A.001 | casingtorque converter | |
| 1 | YDS30.035 | Casing, torque converter | |
| 2 | YDS30.909 | filler cap | |
| 3 | YDS30.049 | tube | |
| 4 | YJH265 | Torque converter | |
| 4 | YJH265D | torque converter | |
| 5 | YDS30.906 | oil pump ass’y | |
| 6 | YDS30.100 | gasket | |
| 7 | GB/T5789-1986 | Bolt | |
| 8 | GB/T5789-1986 | Bolt | |
| 9 | YDS30.144 | Gasket | |
| 10 | YDS30.103 | plug | |
| 11 | YDS30.104 | plug | |
| 12 | YDS30.038 | washer | |
| 13 | GB/T5783-2000 | Bolt | |
| 14 | GB/T5783-2000 | Bolt | |
| 15 | GB/T5783-2000 | Bolt | |
| 16 | GB/T5783-2000 | Bolt | |
| 17 | GB/T93-1987-10 | spring washer | |
| 18 | GB/T119.1-2000-10 | Pin | |
| 19 | 15X2.4GB1235-76 | O-ring | |
| 20 | YDS30.136 | Casing | |
| 21 | YDS30.072 | Bearing seat | |
| 22 | YDS30.089 | bolt | |
| 23 | YDS30.082 | Shim | |
| 24 | YDS30.901 | Clutch assy | |
| 25 | YDS30.025 | shaft | |
| 26 | 6206GB/T276-1994 | Deep groove ball bearing | |
| 27 | YDS30.037 | gear | |
| 28 | GB/T893.1-1986-24 | Ring | |
| 29 | 6207GB/T276-1994 | Deep groove ball bearing | |
| 30 | YDS30.036 | out-gear | |
| 31 | YDS30DY.002 | Shaft | |
| 32 | 32208GB/T297-1994 | Tapered roller bearing | |
| 33 | 30208GB/T297-1994 | Tapered roller bearing | |
| 34 | YDS30.023 | oil-seal cage | |
| 35 | 80X3.1GB1235-76 | O-ring | |
| 36 | 12163-82131 | Oil-seal | |
| 37 | YDS30.024 | nut | |
| 38 | YDS30.019 | washer | |
| 39 | YDS30.019 | washer | |
| 40 | YDS30.019 | washer | |
| 41 | YDS30.020 | Bush | |
| 42 | YDS30.022 | washer | |
| 43 | YDS30.022 | washer | |
| 44 | YDS30.022 | washer | |
| 45 | YDS30.021 | bearing blade | |
| 46 | GB/T5783-2000 | Bolt | |
| 47 | GB/T93-1987-8 | spring washer | |
| 48 | GB/T5786-2000 | Bolt | |
| 49 | YDS30.112 | cover | |
| 50 | GB/T818-2000 | Screw | |
| 51 | GB/T70.1-2000 | Bolt | |
| 52 | YDS30.133 | oil filler seat | |
| 53 | YDS30.134 | paper washer | |
| 54 | YBS3.814 | filer ass’y | |
| 55 | YDS30.135 | rod screw | |
| 56 | GB/T6181-1986 | Nut | |
| 57 | GB/T91-2000 | Cotter pin | |
| 58 | YBS5.133 | seal | |
| 59 | 18JB/T982-1977 | Washer | |
| 60 | YDS30.069 | plate | |
| 61 | YDS30.102 | Plug | |
| 62 | 24X2.4GB1235-76 | O-ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
