Каталог запасных частей к технике: SEM921. Rotary Worm Gear Box
1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
16
17
17
18
18
19
20
21
22
23
24
25
26
26
27
27
28
29
30
31
32
33
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 5739305 | Bolt | |
| 2 | 5189730 | Washer | |
| 3 | 5486394 | Cover | |
| 4 | 5246897 | Screw | |
| 5 | B040811025 | Bolt | |
| 6 | 5757313 | Washer | |
| 7 | 5364112 | She | |
| 8 | 5486395 | Washer | |
| 9 | 5362913 | Oil level indicator | |
| 10 | 5402646 | Key | |
| 11 | 5371675 | Shaft | |
| 12 | 5522621 | Boss | |
| 13 | 5272022 | Oil seal | |
| 14 | 5531344 | Screw | |
| 15 | 5486398 | Bearing seat | |
| 16 | 5486397 | Shaft sleeve | |
| 17 | 5371474 | Tapered roller bearing | |
| 18 | 5362250 | Plant | |
| 19 | 5362757 | Worm | |
| 20 | 5362396 | Drive wheel | |
| 21 | 5371649 | Tapered roller bearing | |
| 22 | 5370342 | Seal-lip type | |
| 23 | 5486396 | Screw | |
| 24 | 5370053 | Oil seal | |
| 25 | 5486399 | Bearing seat | |
| 26 | 5757314 | Washer | |
| 27 | 5486401 | Plug | |
| 28 | 5362758 | Turbine | |
| 29 | 5486400 | Cover | |
| 30 | 5362675 | Shim | |
| 31 | 5395909 | Tapered roller bearing | |
| 32 | 5371641 | Bearing seat | |
| 33 | 5370568 | Seal spacer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
